Description
- Capture HDMI + embedded audio
- Loop-through HDMI signal
- Audio input via mic
- Extract HDMI embedded audio output via headphones
- Support 4Kp60 4:2:0 input. Capture from the newest game consoles such as PS4 Pro and XBOX One S. Automatically down scale to 2K for recording or streaming
Interface
Input Interface & Loop-through Interface
- One HDMI input + embedded audio
- One HDMI loop-through
- Support input & loop-through resolution up to 4096×2160 pixels
Audio Input/Output Interface
- 3.5mm audio jack for microphone/ headphones
Host Interface
- USB 3.0, compatible with USB 2.0
OS
- Windows, Linux, Mac, Chrome OS
Capture Format
- Support capture resolutions up to 2048x2160
- Support capture frame rates up to 120fps
- Capture 2-channel embedded audio or analog audio via 3.5mm microphone interface
Included Software
- USB Capture Utility, Capture Express, etc.
Compatible Software
- Zoom Rooms, Microsoft Teams Rooms, Skype for Business, Google Hangouts, GoToMeeting, VLC, OBS Studio, XSplit, etc.
Others
- Auto detection of input signal format
- Integrate the functions of a USB audio card. Playback audio via 3.5mm headphones interface
- Windows, Linux and Mac SDK
- Continuously work for 24hx7
- LED status indicator
- 3-year warranty
- Form factor: 98.1mm (L) x 56.8mm (W) x 17mm (H)
