Description
A dedicated HDMI streaming encoder with loop-through
- Live streaming to popular services such as Facebook Live, YouTube or Twitch
- Streams to a custom-specified RTMP or RMTPS server and supports sending RTSP streams
- Records video to the internal storage, a connected USB drive or an associated smartphone
- Internet connectivity via wired Ethernet, Wi-Fi and optional 3G/4G modem support
HDMI Specific Features
- Support for up to 4096x2160 4:4:4/4:2:2 30fps or 4096x2160 4:2:0 60fps input and loop-through signals
Audio Input/Output
- Add narration through the analog microphone input
- Monitor the input signal through the analog headphone output
Encoding Features
- H.264 or HEVC (video) and AAC High Quality (audio) encoding; Video bitrates up to 8Mbps
Streaming Features
- Stream to servers or platforms based on RTMP or RTMPS protocol
- Stream to 2 servers simultaneously
- Support for RTSP protocol
Recording Features
- Record to internal storage (32GB), USB flash drive or the associated smartphone
- Record as MP4 or MOV files
Others
- Internet connectivity via wired Ethernet, Wi-Fi or optional 3G/4G modem support
- Control via on-device buttons, intuitive smartphone app or browser-based interface
- HTTP-based APIs for custom integration
