Description
Includes: IP PowerKon Power Cord, Omega Bracket Control: 3-pin DMX, 5-pin DMX
W warm-white LEDs and 20 x 2.63W amber LEDs. An emulated amber shift warms the color temperature of the light as it dims to mimic incandescent lights.
The STRIKE Array 4 features individual pan (or tilt depending on orientation) of each head to allow for directional adjustments to the light output. An innovative interlocking system allows you to connect multiple STRIKE Array 2 and STRIKE Array 4 blinders together for a massive and dramatic output. Additionally, the fixture offers multiple mounting locations for creative and convenient rigging options.
The unit's IP-rated direct power and DMX connections eliminate undesirable whips. You can control it with adjustable pulse width modulation and remote device management for added flexibility. The STRIKE Array 4 ships with an omega bracket and a Seetronic Powerkon IP65 power cord.
Intense 4 pod blinder/strobe rated IP65 for all-weather use
Emulated redshift to mimic incandescent fixtures perfectly
Individual pan (or tilt, depending on mount orientation) of each head to allow for directional adjustment of light output
Innovative interlocking system to connect multiple STRIKE Array 2 and STRIKE Array 4 blinders together
Multiple mounting locations with ¼ turn adaptors for creative and convenient rigging options
16-bit dimming control for smooth, perfect fades
Strobe functionality for high-impact effects on the fly
Easy to use OLED display
Adjustable Pulse Width Modulation (PWM) and RDM (Remote Device Management) for added flexibility
Key Specs
Fixture Type
Special Design
Light Source
192x White LED - 1.33 W / 2.2 A
20x White LED - 2.63 W / 0.75 A
Colors
Warm White, Amber
Beam Angle
61.5°
Control Protocols
DMX512, RDM
AC Input Power
100 to 240 VAC, 50/60 Hz
Power / Current Consumption
100 VAC, 60 Hz: 243 W / 2.44 A
120 VAC, 60 Hz: 241 W / 2.01 A
208 VAC, 60 Hz: 244 W / 1.18 A
230 VAC, 50 Hz: 245 W / 1.07 A
240 VAC, 50 Hz: 247 W / 1.03 A
Show More
Mounting
Omega Bracket
Light
Fixture Type
Special Design
Light Source
192x White LED - 1.33 W / 2.2 A
20x White LED - 2.63 W / 0.75 A
Expected Lamp Life
50,000 Hours
Colors
Warm White, Amber
Photometrics
64 fc / 684 Lux at 16.4' / 5 m
Color Temperature
2770K
Beam Angle
61.5°
Field Angle
100.5°
Shutter / Strobe
Electronic
Iris
No
Dimming
16-Bit Electronic, 0 to 100% with 4 Dimmer Modes
Performance
Operating Modes
Automatic, DMX
Macros / Programs
6x Auto-Program
Effects
Blinder
Strobe Rate
0 to 25 Hz
Gobos
No
Control
Control Protocols
DMX512, RDM
DMX Channel Modes
6 Mode(s):
1 / 3 / 4 / 5 / 6 / 10-Channel
Display / Controls
OLED / 4-Button
Remote Control
No
Connectivity
Inputs/Outputs
2 x XLR 5-Pin DMX Input/Output
AC Input Power
100 to 240 VAC, 50/60 Hz
AC Power Connector
Input: 1x Seetronic IP-Rated
Output: 1x Seetronic IP-Rated
Plug Type: NEMA 5-15
Cord Length: 4.9' / 1.5 m
Fuse
No
Power / Current Consumption
100 VAC, 60 Hz: 243 W / 2.44 A
120 VAC, 60 Hz: 241 W / 2.01 A
208 VAC, 60 Hz: 244 W / 1.18 A
230 VAC, 50 Hz: 245 W / 1.07 A
240 VAC, 50 Hz: 247 W / 1.03 A
Power Linking
5 Units at 100 VAC
6 Units at 120 VAC
11 Units at 208 VAC
12 Units at 230 VAC
12 Units at 240 VAC
Environmental
Environmental Protection
Dust/Water-Resistant (IP65)
Physical
Mounting
Omega Bracket
Duty Cycle
No
Exterior Color
Black
Dimensions
18.5 x 16.7 x 6.3" / 469.9 x 424.2 x 160 mm
Weight
28.7 lb / 13 kg
