Description
Includes: IP PowerKon Power Cord, Omega Bracket Control: 3-pin DMX, 5-pin DMX
Lighting designers in search of a powerful, outdoor-ready audience blinder will be impressed with the Chauvet Professional STRIKE Array 2 an intense two-pod blinder/strobe that's rated IP65 for temporary outdoor/wet use, with pressure equalizing, M12 GORE valve. The light is powered by 96 x 1.33W warm-white LEDs and 10 x 2.63W amber LEDs. An emulated amber shift warms the color temperature of the light as it dims to mimic incandescent lights.
The STRIKE Array 2 features individual pan (or tilt depending on orientation) of each head to allow for directional adjustments to the light output. An innovative interlocking system allows you to connect multiple STRIKE Array 2 and STRIKE Array 4 blinders together for a massive and dramatic output. Additionally, the fixture offers multiple mounting locations for creative and convenient rigging options.
The unit's IP-rated direct power and DMX connections eliminate undesirable whips. You can control it with adjustable pulse width modulation and remote device management for added flexibility. The STRIKE Array 2 ships with an omega bracket and a Seetronic Powerkon IP65 power cord.
Intense 2 pod blinder/strobe rated IP65 for temporary wet use
Emulated red shift to mimic incandescent fixtures perfectly
Individual pan (or tilt, depending on mount orientation) of each head to allow for directional adjustment of light output
Innovative interlocking system to connect multiple STRIKE Array 2 and STRIKE Array 4 blinders together
Multiple mounting locations with ¼ turn adaptors for creative and convenient rigging options
16-bit dimming control for smooth, perfect fades
Strobe functionality for high-impact effects on the fly
Easy to use OLED display
Adjustable Pulse Width Modulation (PWM) and RDM (Remote Device Management) for added flexibility
Fixture Type
Special Design
Light Source
96x White LED - 1.33 W / 2.2 A
10x White LED - 2.63 W / 0.75 A
Colors
Warm White, Amber
Beam Angle
60.3°
Control Protocols
DMX512, RDM
AC Input Power
100 to 240 VAC, 50/60 Hz
Power / Current Consumption
100 VAC, 60 Hz: 124 W / 1.24 A
120 VAC, 60 Hz: 123 W / 1.04 A
208 VAC, 60 Hz: 127 W / 0.61 A
230 VAC, 50 Hz: 129 W / 0.56 A
240 VAC, 50 Hz: 130 W / 0.54 A
Show More
Mounting
Omega Bracket
Light
Fixture Type
Special Design
Light Source
96x White LED - 1.33 W / 2.2 A
10x White LED - 2.63 W / 0.75 A
Expected Lamp Life
50,000 Hours
Colors
Warm White, Amber
Photometrics
33 fc / 360 Lux at 16.4' / 5 m
Color Temperature
2792K
Beam Angle
60.3°
Field Angle
99°
Shutter / Strobe
Electronic
Iris
No
Dimming
Electronic, 0 to 100% with 4 Dimmer Modes
Performance
Operating Modes
Automatic, DMX
Macros / Programs
6x Auto-Program
Effects
Blinder
Strobe Rate
0 to 25 Hz
Gobos
No
Control
Control Protocols
DMX512, RDM
DMX Channel Modes
6 Mode(s):
1 / 2 / 3 / 4 / 5 / 8-Channel
Display / Controls
OLED / 4-Button
Remote Control
No
Connectivity
Inputs/Outputs
2 x XLR 5-Pin DMX Input/Output
AC Input Power
100 to 240 VAC, 50/60 Hz
AC Power Connector
Input: 1x Seetronic IP-Rated
Output: 1x Seetronic IP-Rated
Plug Type: NEMA 5-15
Cord Length: 4.9' / 1.5 m
Fuse
No
Power / Current Consumption
100 VAC, 60 Hz: 124 W / 1.24 A
120 VAC, 60 Hz: 123 W / 1.04 A
208 VAC, 60 Hz: 127 W / 0.61 A
230 VAC, 50 Hz: 129 W / 0.56 A
240 VAC, 50 Hz: 130 W / 0.54 A
Power Linking
11 Units at 100 VAC
13 Units at 120 VAC
22 Units at 208 VAC
24 Units at 230 VAC
25 Units at 240 VAC
Environmental
Environmental Protection
Dust/Water-Resistant (IP65)
Physical
Mounting
Omega Bracket
Duty Cycle
No
Exterior Color
Black
Dimensions
18.5 x 10.4 x 6.3" / 469.9 x 264.2 x 160 mm
Weight
17.6 lb / 8 kg
