Description
Based on their popular 1" diameter remote phosphor LED Pipes, the 4' long 5600K Pipeline Reflect from BB&S is designed with the Pipe ensconced in a polished aluminum reflector with a 2" opening that compresses the angle of illumination to 90° and doubles the output, as compared to Pipes when used alone. As you might expect with a remote phosphor, the fixture has an impressive TLCI rating of 95, an indicator of high accuracy in color rendering.
The reflector is the core of the fixture's system offering wide latitude of power and control options. It has sliding mount plates with 3/8" and 1/4" female threads. The unit also has a 3-pin XLR connection that interfaces with an optional controller with four 40W channels for operating multiple fixtures. The controller also has an onboard DMX and RDM for remote operation from a console, while it also has a provision for wireless DMX. The controller features precise dimming and a 48V power supply with a powerCON True-1 locking cable for AC power. An optional manual-control dimmer/driver unit, a D-Tap cable for 14.4 VDC batteries, and an optional AC power supply are also available.
The Reflect System
Pipeline Reflect incorporates a range of reflectors offering optimal control and light dispersion spanning a 90° angle with practically no spill. The Reflect System offers double the foot-candle output of the Pipe alone. Like all BB&S fixtures, the versatile Pipeline Reflect features offer strobe capability when used with the optional BB&S 4-way controller.
Outstanding Color Rendering
The Reflect System utilizes the same 95 TLCI color-accurate rendering remote phosphor 1" diameter LED Pipes that Pipeline is known for. Available in lengths from 1' to 8', Reflect housings are made of rigid, polished aluminum with a contoured base, 1.5" high sidewalls, and a 2" wide opening. Smart engineering compresses the angle of illumination to double the output compared to Pipes used alone.
Ideal for the Studio
Reflect fixtures are available in 1, 2, 3, 4, 6, and 8' lengths. They are ideal for studio grids or anchor desks. Set designers will appreciate that the housing is black for a clean-looking installation.
Variety of Control Options
Made for customization, Reflect units feature a 3-pin XLR plug to allow the user to control the electronic configuration. For plug and play, fixtures can operate with the BB&S 4-way controller (which has four 40W channels) with optional wireless DMX/RDM control. All Pipes run off 48V for precise dimming.
Easy Mounting
Optional controllers can be wall or ceiling mounted. The 3-pin XLR mounted within the fixture results in a cleaner installation.
Optional DMX and Battery power
The Pipeline Reflect is compatible with the 4-way controller with DMX/RDM 512 onboard. An optional battery can power the fixture when AC power is not available.
Item Type
1 x LED Light Tube/Wand
Included Storage Case
No
Photometrics
90° at 5600K:
175 fc / 1890 Lux at 3.3' / 1 m*
20 fc / 210 Lux at 9.84' / 3 m
*Standardized Measurement Calculated Internally Based on Closest Distance
Show More
Color Temperature
5600K
Color Modes
Daylight
Color Accuracy Standard
TLCI 95
Dimming
Controller Not Included
Beam Angle
90°
Front Accessory Mount
Proprietary
Wireless Remote Control Type
Wireless DMX *Adapter Required (Not Included)
Power Source
AC to DC Adapter (Not Included)
Battery (Not Included)
AC Input Power
100 to 240 VAC, 50 / 60 Hz
DC Input Power
40 VDC
Power Consumption
40 W
Fixture Mounting
Not Specified by Manufacturer
Light Fixture
Item Type
1 x LED Light Tube/Wand
Included Filters
Phosphor Panel (Built-In)
Included Storage Case
No
Photometrics
90° at 5600K:
175 fc / 1890 Lux at 3.3' / 1 m*
20 fc / 210 Lux at 9.84' / 3 m
*Standardized Measurement Calculated Internally Based on Closest Distance
Color Temperature
5600K
Color Modes
Daylight
Color Accuracy Standard
TLCI 95
Dimming
Controller Not Included
Cooling System
Passive
Beam Angle
90°
Built-In Flash
No
Front Accessory Mount
Proprietary
Connectivity
Wireless Remote Control Type
Wireless DMX *Adapter Required (Not Included)
Max DMX Control Channels
512
Power & I/O
Power Source
AC to DC Adapter (Not Included)
Battery (Not Included)
Inputs/Outputs
1 x XLR 3-Pin Power/DMX Input
AC Input Power
100 to 240 VAC, 50 / 60 Hz
DC Input Power
40 VDC
Power Pass-Thru
No
Power Consumption
40 W
Mounting
Fixture Mounting
Not Specified by Manufacturer
Included Adapter
1 x Non-Swivel Mount: 1/4"-20 Male Screw to Proprietary
1 x Non-Swivel Mount: 3/8"-16 Male Screw to Proprietary
Environmental
Environmental Protection
No
Operating Temperature
-4 to 104°F / -20 to 40°C
General
Display
No
Materials
Aluminum (Housing)
Dimensions
48 x 1" / 121.92 x 2.54 cm (Fixture Panel)
