Description
Based on their popular 1-inch diameter remote phosphor LED Pipes, the 2' long 5600K Pipeline Reflect 2-Bank from BB&S raises its own performance bar with the inclusion of two LED Pipes for double the power, inside a reflector with a tilting yoke and a receiver.
The Reflect 2-Bank is designed with the Pipes nested in a polished aluminum reflector with a 2" opening that compresses the angle of illumination to 90° and doubles the output as compared to the standard Reflect fixture. As you might expect with a remote phosphor, the fixture has an impressive TLCI rating of 95, an indicator of high accuracy in color rendering.
The reflector is the core of the fixture's system offering wide latitude of power and control options. It has a sliding mount plate with 1/4" and 3/8" female threads. The unit also has a 3-pin XLR connection that interfaces with an optional controller that has four 40W channels for operating multiple fixtures. The controller also has an onboard DMX and RDM for remote operation from a console, as well as provision for wireless DMX. The controller features precise dimming and a 48V power supply with a powerCON True-1 locking cable for AC power. An optional manual-control dimmer/driver unit, a D-tap cable for 14.4 VDC batteries, and an optional AC power supply are also available.
Fully Outfitted Studio Fixture with Twice the Power of Standard Reflect
The 2-Bank Reflect uses two Pipeline LED tubes to double the power of the standard Reflect fixture, which itself offers double the power of the LED tube alone. The 2-Bank also comes with a tilting yoke with a receiver that makes stand mounting or overhead hanging a snap.
The Reflect System
Pipeline Reflect incorporates a range of superior quality reflectors offering optimal control, and light dispersion spanning a 90° angle with practically no spill. The Reflect System offers double the foot-candle output of the Pipes alone. As with all BB&S fixtures, the versatile Pipeline Reflect feature offers strobe capability when used with the optional BB&S 4-Way Controller.
Outstanding Color Rendering
The Reflect System utilizes the same 95 TLCI-rated remote phosphor 1" diameter LED pipes that the Pipeline system is known for. Reflect housings are made of rigid, polished aluminum with a contoured base. Smart engineering compresses the angle of illumination to double the output compared to Pipes used alone.
Ideal for the Studio
Reflect 2-Bank fixtures are available in 2, 3, 4, 6, and 8' lengths. They are ideal for studio grids or anchor desks. Set designers will appreciate that the housings are black for a clean-looking installation.
Variety of Control Options
Made for customization, Reflect units feature a 3-pin XLR plug to allow you to control the electronic configuration. To plug and play, a fixture can operate with the BB&S 4-Way Controller (which has four 40W channels) with optional wireless DMX or RDM control. All Pipes run off 48V for precise dimming.
Easy Mounting
Optional controllers can be mounted on the wall or ceiling. The 3-pin XLR connector within the fixture results in a cleaner installation.
Optional DMX and Battery power
The Pipeline Reflect is compatible with the 4-way controller with DMX/RDM 512 onboard. Optional batteries can also power the fixture when AC power is unavailable.
Item Type
1 x LED Light Bank/Frame Fixture with 2 Light Tubes
Included Storage Case
No
Photometrics
Unspecified Color Temperature:
177 fc / 1916 Lux at 3.3' / 1 m*
44 fc / 479 Lux at 16.4' / 5 m
19 fc / 213 Lux at 23' / 7 m
*Standardized Measurement Supplied by the Manufacturer
Show More
Color Temperature
5600K
Color Modes
Daylight
Color Accuracy Standard
TLCI 95
Dimming
Controller Not Included
Beam Angle
90°
Front Accessory Mount
Proprietary
Wireless Remote Control Type
Wireless DMX *Adapter Required (Not Included)
Power Source
AC to DC Adapter (Not Included)
Battery (Not Included)
AC Input Power
100 to 240 VAC, 50 / 60 Hz
DC Input Power
40 VDC
Power Consumption
40 W
Fixture Mounting
1 x 5/8" Receiver (Via Yoke Mount)
Light Fixture
Item Type
1 x LED Light Bank/Frame Fixture with 2 Light Tubes
Included Filters
Phosphor Panel (Built-In)
Included Storage Case
No
Lumens
6000 (at 5600K)
Photometrics
Unspecified Color Temperature:
177 fc / 1916 Lux at 3.3' / 1 m*
44 fc / 479 Lux at 16.4' / 5 m
19 fc / 213 Lux at 23' / 7 m
*Standardized Measurement Supplied by the Manufacturer
Color Temperature
5600K
Color Modes
Daylight
Color Accuracy Standard
TLCI 95
Dimming
Controller Not Included
Cooling System
Passive
Beam Angle
90°
Built-In Flash
No
Front Accessory Mount
Proprietary
Connectivity
Wireless Remote Control Type
Wireless DMX *Adapter Required (Not Included)
Power & I/O
Power Source
AC to DC Adapter (Not Included)
Battery (Not Included)
Inputs/Outputs
1 x XLR 3-Pin Power/DMX Input
AC Input Power
100 to 240 VAC, 50 / 60 Hz
DC Input Power
40 VDC
Power Pass-Thru
No
Power Consumption
40 W
Mounting
Yoke Type
Manually-Operated Yoke
Fixture Mounting
1 x 5/8" Receiver (Via Yoke Mount)
Environmental
Environmental Protection
No
General
Display
No
Materials
Aluminum (Housing)
Dimensions
24 x 1" / 60.96 x 2.54 cm (Fixture Panel)
