Enhance your newsroom and studio productions with the 5600K Reflect Daylight LED Light 4-Bank from BB&S Lighting. Featuring four 1' LEDs ensconced in a sturdy yet lightweight reflector, this multi-lamp setup outputs an 80° defined angle. The Reflect LED system boasts a TLCI rating of 95, an indicator of high accuracy in color rendering. Also, users will benefit from a full-range smooth dimming with no color shift or flickering, either onboard or remotely via DMX (optional accessories are required). The fixture was thoughtfully designed for situations where the ceiling height is limited.
Slim Design, Efficient LEDs
The Reflect 4-bank system was created to deliver both precise color rendering and the longevity benefits of the efficient LEDs that BB&S Lighting is known for. The unit's included mini yoke is conveniently adjustable and made to fit ceilings with lower load capabilities. Set designers will also appreciate that the housing is black for a clean-looking installation.
Bright Output, Soft Light Capability
This rectangular unit yields 1681 lux at 3.3' with a maximum power consumption of 40W per foot. For situations where a wider and softer beam is needed, an optional top diffuser can be inserted and secured in each section of the 4-bank, dispersing a 110° angle that mimics a softbox effect.
Optional Accessories
This model requires either a separately available 3-pin cable, a dimmer/power supply, or a DMX controller. Barndoors, louvers, and other modifiers are also sold separately.
Item Type
1 x LED Light Tube/Wand
Included Storage Case
No
Photometrics
5600K:
156 fc / 1681 Lux at 3.3' / 1 m (Unmodified)*
17 fc / 187 Lux at 9.8' / 3 m (Unmodified)
6 fc / 67 Lux at 16.4' / 5 m (Unmodified)
*Standardized Measurement Supplied by the Manufacturer
Show More
Color Temperature
5600K
Color Modes
Daylight
Color Accuracy Standard
CRI 94
TLCI 95
Dimming
Controller Not Included
Beam Angle
80°
Front Accessory Mount
Proprietary
Wireless Remote Control Type
Wireless DMX *Adapter Required (Not Included)
Power Source
AC to DC Adapter (Not Included)
DC Input Power
48 VDC
Power Consumption
40 W
Fixture Mounting
Not Specified by Manufacturer
Light Fixture
Item Type
1 x LED Light Tube/Wand
Included Storage Case
No
Photometrics
5600K:
156 fc / 1681 Lux at 3.3' / 1 m (Unmodified)*
17 fc / 187 Lux at 9.8' / 3 m (Unmodified)
6 fc / 67 Lux at 16.4' / 5 m (Unmodified)
*Standardized Measurement Supplied by the Manufacturer
Color Temperature
5600K
Color Modes
Daylight
Color Accuracy Standard
CRI 94
TLCI 95
Dimming
Controller Not Included
Cooling System
Passive
Beam Angle
80°
Built-In Flash
No
Umbrella Mount
No
Front Accessory Mount
Proprietary
Connectivity
Wireless Remote Control Type
Wireless DMX *Adapter Required (Not Included)
Mobile App Compatible
No
Power & I/O
Power Source
AC to DC Adapter (Not Included)
Inputs/Outputs
1 x XLR 3-Pin Power/DMX Input
DC Input Power
48 VDC
Power Consumption
40 W
Mounting
Yoke Type
Manually-Operated Yoke
Fixture Mounting
Not Specified by Manufacturer
Environmental
Environmental Protection
No
Operating Temperature
-4 to 104°F / -20 to 40°C
General
Display
No
Dimensions
12 x 8" / 30.5 x 20.3 cm
Weight
6 lb / 2.7 kg
