Description
- Connects baseband presentation or distribution equipment into IP-based media networks
- Supports NDI technology including NDI High Bandwidth and high-efficiency NDI HX mode
- Supports streaming protocols including SRT, RTSP, RTMP, UDP, RTP, HLS and HTTP
Output Features
- Support for up to 1920x1080 60fps SDI output
- Support for 48KHz, 16-bit 8-channel audio streams
Decoding Features
- Decoding up to 2Kp60 streams of NDI High Bandwidth, NDI HX, NDI HX2, NDI HX3, RTSP, HTTP, HLS, RTMP Pull/Push, and MPEG-TS over UDP/SRT/RTP protocols
- SpeedHQ/H.264/H.265 video decoders
- Support NDI 6.3
- Discover NDI devices across network segments
Features & Advantages
- Very low latency
- Advanced configuration and device status through intuitive Web GUI, keyboard/mouse, or on-board controls
- HTTP-based APIs for custom integration
- Image flip for inverted projector installations
- Safe area controls
- Provide Crestron Plugins
- Provide Q-SYS Control Plugins
