Description
Converts a live IP stream into HD HDMI signal
- Connects baseband presentation or distribution equipment into IP-based media networks
- Decodes NDI High Bandwidth or NDI HX including earlier variants into HD HDMI
- Up-converts the decoded HD signals to 4K for viewing on Ultra HD displays
- Magewell offers accesories to mount this model on the 1RU rack. A module-type product of the same specification is also available for use with the Magewell Modator chassis for high-density deployment.
Output Features
- Support for up to 4096x2160 60fps HDMI output (integrated up-conversion from HD sources)
- Support for 96KHz, 16-bit 8-channel audio streams
Decoding Features
- Decoding up to 2Kp60 streams of NDI High Bandwidth, NDI HX, NDI HX2, NDI HX3, RTSP, HTTP, HLS, RTMP Pull/Push and MPEG-TS over UDP/SRT/RTP protocols
- SpeedHQ/H.264/H.265 video decoders
- Support NDI 6.3
- Discover NDI devices across network segments
Features & Advantages
- Very low latency
- Advanced configuration and device status through intuitive Web GUI, keyboard/mouse, or on-board controls
- HTTP-based APIs for custom integration
- Image flip for inverted projector installations and safe area controls
- Automatic output optimization for target display with integrated up/down conversion
- Provide Crestron Plugins
- Provide Q-SYS Control Plugins
