Description
Includes: Medium, and Wide Lenses, powerCON Power Cord, Control: 3-pin DMX, 5-pin DMX
The CHAUVET PROFESSIONAL Ovation P-56VW PAR Light is a compact and virtually silent PAR fixture that produces a homogenized, single-source, flat, and even field of variable white light with high CRI and CQS. The light source includes six red, six green, ten blue, four royal blue, six orange, and 16 lime for a total of 48 LEDs which produce nearly any temperature of white. The PAR's color temperature can be even further adjusted for +/- green, making it ideal for TV studios and broadcasted events. When used with the included interchangeable lens plate beam-shaping accessories, the P-56VW can produce wide beam angles for theatrical and studio applications.
The virtually silent and bright PAR features smooth 16-bit dimming, as well as RDM and PWM for easy setup. Other features include four dimming modes, DMX and RDM control, DMX channels 3, 5, 6, 8, 11, 15 or 17, seven personalities, and both 3- and 5-pin XLR DMX connectors.
Variable white PAR-style fixture with homogenized single source of light
Interchangeable lens plates included for medium and wide beam angles
Soft, even field of light
Quiet operation for use in any situation with fan speed control
+/- green adjustment via DMX or onboard control
Independent color control over the 6-color engine when a splash of color is needed
RDM and variable Pulse Width Modulation for setup ease
Accepts standard 7.5” beam-shaping accessories
16-bit dimming resolution for smooth fades
Optical
Light Source: 48 LEDs (6 Red, 6 Green, 10 Blue, 4 Royal Blue, 6 Orange, 16 Lime) 3 to 4 W, (1 A)
Life Expectancy: 50,000 Hours
Color Temperature (Range): 2800 to 8000K
CRI: 92-93
Beam Angle (Medium Lens): 21°
Beam Angle (Wide Lens): 54°
Beam Angle (Wide Lens with Egg Crate): 40°
Field Angle (Medium Lens): 35°
Field Angle (Wide Lens): 84°
Field Angle (Wide Lens with Egg Crate): 66°
Lumens (Medium Lens): 3967
Lumens (Wide Lens): 4476
Illuminance (Medium Lens): 1220 Lux at 16.4' / 5.0 m
Illuminance (Wide Lens): 220 Lux at 16.4' / 5.0 m
Selectable PWM: 600, 1200, 2000, 4000, 6000, 25,000 Hz
Dynamic Effects
Dimmer: Electronic
Shutter/Strobe: Electronic
Strobe Rate: 0 to 29 Hz
Focus: Manual
Standalone Color Mixing: Yes
Color Temperature Presets: Yes
Dim Modes: 4
Built-In Automated Programs: Yes
Connections
Power Connection: Edison (Local) Plug to Neutrik powerCON
Data Connectors: 3- and 5-Pin XLR
Cable Length (Power): 5' / 1.5 m
Control
Control Protocol: DMX, RDM
DMX Channels: 3, 5, 6, 8, 11, 15, 17
Modes/Personalities: 7 Personalities (3, 5, 6, 8, 11, 15, 17)
Electrical
Input Voltage: 100 to 240 VAC, 50/60 Hz (Auto-Ranging)
Power Linking: 11 Units at 120 V; 18 Units at 208 V; 20 Units at 230 V
Power and Current: 150 W, 1.22 A at 120 V, 60 Hz
Power and Current: 155 W, 0.70 A at 208 V, 60 Hz
Power and Current: 158 W, 0.66 A at 230 V, 50 Hz
Certifications
CE, MET
IP Rating: IP20, Dry Location
Temperature (Ambient): -4 to 113°F / -20 to 45°C
Material of Construction
Housing Material: Aluminum Die-Cast
Accessory Holder/Gel Frame Size: 7.5" / 19.1 cm
Dimensions
12.5 x 12.8 x 14.3" / 31.7 x 32.6 x 36.3 cm
Weight
12.0 lb / 5.5 kg
