Description
Most suitable applications: Touring and live events
PoE: Optional on front ports only (up to 160W)
RLinkX (Link redundancy): Yes
Groups (VLAN segmentation): Yes
MultiLinkX (Link aggregation): Yes
Profile manager: Yes
Memory: 4Mb
MAC address table: 8192 Entries
Address learning / Aging: Self learning, Auto aging
Switching throughput: 32Gbps
Jumbo frames: MTU up to 9600
IGMP support: Yes (V1/V2/V3)
IGMP snooping: Yes, enabled by default
Port sensing: Auto negotiation
Auto crossover: MDI / MDIX
Auto sensing: Full or Half Duplex (Gigabit is Full Duplex) Power connectivity:
1 x IEC (14C) inlet with fuse holder
1 x redundant power input on Molex Micro-Fit 6 pin connector
1 x redundant PoE input on Molex Micro-Fit 6 pin connector
Power input: 100-240VAC, 50-60Hz
Power consumption: Maximum 30W Maximum 180W with PoE
Fuse: 3.15A 250V Slow Blow
Backup power input: 15VDC / 2A
Backup PoE power input: 48VDC / 3.4A
PoE: Optional on front ports only (up to 160W) Mounting: Rack
Enclosure: Robust metal housing
Dimensions (W x D x H): 482 x 204,3 x 44 mm (19″ x 8.04″ x 1.73″)
Weight: 3 kg
Packaging: 545 x 335 x 80 mm (21,5" x 13,2" x 3,15")
Environment:
Operating temperature: 0 to +50 °C
Storage temperature: -10 to +70 °C
Humidity (non condensing): 5 to 95% RH
Noise level @1m:
Max 30dBA (PoE or Non PoE, Ambient: 0 – 35°C)
Max 42dBA (PoE or Non PoE, Ambient: 35 – 50°C)
BTU:
Certificates/Approvals: CE, RoHS
Standards: EN 60950-1, EN 55022, EN 55024
