• Most suitable applications: Touring and live events
• PoE: Optional on front ports only (up to 160W)
• RLinkX (Link redundancy): Yes
• Groups (VLAN segmentation): Yes
• MultiLinkX (Link aggregation): Yes
• Profile manager: Yes
• Memory: 4Mb
• MAC address table: 8192 Entries
• Address learning / Aging: Self learning, Auto aging
• Switching throughput: 32Gbps
• Jumbo frames: MTU up to 9600
• IGMP support: Yes (V1/V2/V3)
• IGMP snooping: Yes, enabled by default
• Port sensing: Auto negotiation
• Auto crossover: MDI / MDIX
• Auto sensing: Full or Half Duplex (Gigabit is Full Duplex)
• Ethernet connectivity: 12 x Shielded Neutrik Ethercon connectors
• Fiber connectivity: 4 x slot for rugged fiber connectors
• Ethernet port speed: 1Gbps
• Serial: 1 x serial RJ45 console port
• Mounting: Rack
• Enclosure: Robust metal housing
• Dimensions (W x D x H): 482 x 294,15 x 88,45 mm (19" x 11.5" x 3,5")
• Weight: 6,1 kg
• Packaging: 545 x 420 x 140 mm (21,5" x 16,5" x 5,5")
• Environment:
• Operating temperature: 0 to +50 °C
• Storage temperature: -10 to +70 °C
• Humidity (non condensing): 5 to 95% RH
• Noise level @1m: TBD
• BTU:
• Certificates/Approvals: CE, RoHS
• Standards: EN 60950-1, EN 55022, EN 55024
