Description
Key Specs
Networking I/O
10 Total Connections Supporting up to 10 GbE
Stackable
Yes
Switching Bandwidth
56 Gb/s
PoE Power Budget
450 W
Networking I/O
Each Unit:
8x RJ45 Gigabit Ethernet (Link Aggregation) PoE++ (60 W, 802.3bt Type 3)
2x LC Neutrik opticalCON QUAD Multi-Mode 10 GbE
Stackable
Yes
Protocols
Supported Protocols
Auto-MDIX/MDI
IGMP Snooping
Link Aggregation
MAC Filtering
Port Mirroring
Jumbo Frames Support
12,000 Bytes
MAC Address Table Size
16384K
Performance
Switching Bandwidth
56 Gb/s
Computer
Flash Memory
4 GB
Memory
1 GB
Electrical
PoE Power Budget
450 W
Power Draw
550.00 W (Max)
Input Power
100 to 240 VAC, 50 / 60 Hz
Power Supply Type
Internal
General
Certifications
CB Certificate, CE Mark, RoHS, UKCA Mark, UL cSGSus Mark
Operating Conditions
32 to 104°F / 0 to 40°C up to 95% Humidity
Storage Conditions
32 to 158°F / 0 to 70°C
Cooling System
Fan
Material of Construction
Metal
Indicator Lights
Yes
Rack Mountable
Yes 1 U
Dimensions
13 x 8.7 x 1.7" / 330 x 220 x 44 mm
Weight
7.5 lb / 3.4 kg
