Description
Contractors! Email us to get your approved installer discount code used at checkout* (subject to review)
For custom quotes and layout design inquiries, email contact@TheLAFirm.com
Want to stylishly illuminate your driveway or garden path with a compact, versatile ground spotlight? DOT 22 is perfect for improving visibility and adding an enchanting look to your outdoor space. For optimal effect, place DOT 22 every 1.5 meters.
Want a more playful lighting effect? Then choose from 22 mm or 60 mm sizes. DOT ground spots can be personalized with rings in three different colors, so you can customize them completely to your own taste. Black, Pearl Grey and Stainless Steel.
Moreover, DOT is the only ground spotlight in our range that is compatible with the SMART HUB-300. For detailed installation instructions, see installation advice.
DOT is suitable for all HUBs, including SMART HUB-300.
Available in four variants
Combinable with DOT
Also suitable for SMART HUB-300
Installation advice:
Place a DOT 22 every 1.5 to 2 meters
DOT should be installed in a 22 mm diameter hole. This can be done in wood (with a wood drill bit) or in stone (with a cooled diamond drill bit). A dealer or landscaper can perform this installation for you. Be sure to drill the hole straight and just the right diameter to avoid problems with the lighting's electronics.
Unlike FUSION 22, HYVE 22 and DB-LED, DOT 22 is compatible with SMART HUB-300. The rest of the ground spots connect to: HUB-50, HUB-100 and SMART HUB-150.
SPECS:
Art. nr.: 10101710
Application: Driveway, Path
Mounting depth (inch): 1.9685
Recessed depth (mm): 50
CRI: 97
Diameter (inch): 0.8661
Diameter (mm): 22
EAN code: 8717051006562
Energy label: G
Height (inch): 1.2598
Height (mm): 32
IP class: 68
Light direction: up
Light type: Direct
Efficiency (Lumen/Watt): 6
Net luminous flux (Lumen): 2
Order unit: 6
Power [W]: 0.36
Processing: Concrete, Wood
Article group: Integrated
Voltage: 12V
VA value: 0.5
Color temperature: 2850
Kilowatt hour :1
Luminous intensity [Cd]: 0.8
Power factor: 0,6
