Description
Includes: Includes: IP PowerKon Power Cord, Glare Shield, 2pcs Omega Bracket Control: 5-pin DMX, Artnet, Sacn
Designed for touring, festivals, installations, and theatrical productions, the COLORado Solo Batten 4 Light from CHAUVET PROFESSIONAL is an RGBAW 4-cell LED batten with seamless end-to-end color mixing. This fixture is engineered with four homogenized square sections that can be controlled individually. They appear seamlessly together without separation or dimmed lens corners and create an endless variety of color control and pixel mapping effects. The unit is IP65 rated and equipped with DMX and Ethernet connectivity. An Omega bracket and wall wash filter are included for quick and easy truss/pipe mounting.
Completely homogenized color with no separation or dimmed lens corners
IP-rated power, DMX, and Ethernet connections
Color temperature presets from 3200 to 10,000K
Selectable smooth dimming curves for programming versatility
Built for touring, live event, television, and theatrical productions
Large, easy-to-navigate display with password protection
Built-in automated programs
Customizable programs
Recall custom programs
ptical
Light Source
LEDs: 48 (8 Red, 8 Green, 8 Blue, 8 Amber, 16 White), 3 W (612 mA)
Life Expectancy: 50,000 Hours
Color Temperature
1800 to 8000K
CRI
77.2 (3200K)
Installed Optics
18°
Beam Angle
Horizontal: 18°
Horizontal with Filter: 35°
Vertical: 17°
Vertical with Filter: 16°
Field Angle
Horizontal: 34°
Horizontal with Filter: 66°
Vertical: 30°
Vertical with Filter: 32°
Lumens
3730
Illuminance
1270 Lux at 16.4' / 5 m
With Filter: 432 Lux at 16.4' / 5 m
PWM Frequency
600, 1200, 2000, 4000, 6000, 25,000 Hz (Selectable)
Dynamic Effects
Dimmer
Electronic
Shutter/Strobe
Electronic
Strobe Rate
0 to 25 Hz
Standalone Color Mixing
Yes
Color Temperature Presets
Yes
Dimming
5 Modes
Connections
Power Connection Type
Edison (Local) Plug to Seetronic Powerkon IP65
Power Input
Seetronic Powerkon IP65
Power Output
Seetronic Powerkon IP65
Data Connectors
5-Pin IP65 XLR, Seetronic etherCON IP65
Power Cable Length
5' / 1.5 m
Control
Control Protocol
Art-Net, DMX, Art-Net to DMX, RDM, sACN
DMX Channels
DMX:
1 Cell: 3, 4, 5, 8, 8, 9, 10, 10, 13, 16
4 Cell: 12, 16, 20, 27, 29, 31, 35, 40, 56
Art-Net:
1 Cell: 3, 4, 5, 8, 8, 9, 10, 10, 13, 16
4 Cell: 12, 16, 20, 27, 29, 31, 35, 40, 56
Modes
19 Personalities
Electrical
Input Voltage
100 to 240 VAC, 50/60 Hz (Auto-Ranging)
Power Linking
14 Units at 120 V
24 Units at 208 V
26 Units at 230 V
Power and Current
113 W, 0.96 A at 120 V, 60 Hz (4.2 A Inrush)
110 W, 0.57 A at 208 V, 60 Hz (3.60 A Inrush)
111 W, 0.52 A at 230 V, 50 Hz (2.6 A Inrush)
Resting:
11 W, 0.09 at 120 V, 60 Hz
25 W, 0.12 A at 208 V, 60 Hz
27 W, 0.12 A at 230 V, 50 Hz
Certifications and Approvals
Certification
CE, MET, FCC
IP Rating
IP65, Temporary Outdoor/Wet Use
Ambient Temperature
-4 to 113 °F / -20 to 45 °C
Physical
Exterior Color
Black
Housing Material
Die-Cast Aluminum
Dimensions
14.7 x 9.1 x 10" / 37.2 x 23.0 x 25.3 cm
Accessory Holder / Gel Frame Size: 13.5 x 3.8" / 34.3 x 9.7 cm
Weight
17.2 lb / 7.8 kg
