Description
Tambora Linear 60 (Foam Shell):
240x RGB Background LED, 120x 3.7w High Output
White LED
100-240V, 50/60 Hz ETL IP20
Claypaky CL2021 Tambora Linear 60 LED Bar
Overview
Following on from its successful range of LED bars introduced last year, Claypaky has now expanded the Tambora family further and introduces Tambora Linear 60, an advanced static LED Pixel mapping bars designed for versatile lighting effects and artistic set decoration.
These are hybrid bars, which incorporate two complementary effects into one fixture. The first is driven by a system of 240 RGB pixel LEDs, which offer a background light very similar to that of a high definition LED wall in appearance. This LED array can be controlled as 16 LEDs in 15 groups to provide high quality motion graphics.
The second effect is created by a central line of 120 extremely powerful white LEDs for an overwhelming strobe effect, capable of reproducing the behavior of the most celebrated strobe fixtures on the market. This effect can also be controlled through 15 different areas, offering unparalleled versatility.
All graphic content can be managed through the Advanced Layers Management, an exclusive feature of Claypaky LED bars, with which you can choose to use different levels of effects simultaneously, giving free expression to your creativity.
Tambora Linear 60 features a large number of build-in effects, so it can be used not only in advanced mode but also in a simple mode for whenever a media server is not available, or the installation requires a speedy solution.
The Tambora Linear 60 can be easily connected mechanically with multiple units and then operated as one complete fixture from the control software. This is extremely easy and user friendly to use. For greater compositional modularity we also offer Tambora Linear 100 (1 m lenght).
Claypaky also offers a wide range of easy-to-apply accessory filters. These can shape the beam of light with a frost effect or increase the readability of the pixels with the “neutral density” filter, which is particularly useful for television applications and really enhances the on-camera performance.
Tambora Linear 60 is both sleek and lightweight and has been designed with a slim body, in order to better adapt to many applications. from TV studios to touring, where the need for pixel mapping light sets is increasingly in demand and appreciated. The “hybrid” nature of Tambora is perfect for this need and provides a two in one versatility. This is a truly distinctive product within each lighting set, at a truly competitive price.
Features
Light Source
RGB LEDs and one line of white strobe
Light Output
10,114 lm
Zoom range
White strobe 120° of beam aperture RGB LEDs 35°x63° @50% - 52°x65° @10%
Effects
240pcs 3-in-1 RGB leds, splitted into 16 areas; 120pcs white leds, splitted into 16 areas; Advanced Layer Management; White CT emulation 2800-8000K; RGB and Strobe Shape effect; Electronic linear dimmer, 24 bit and 5 curves; Electronic strobe/stop from 0.3 to 25 f/sec
