Description
Sharpy X-Spot:
550w Lamp, 8000k, 1500hrs
100-240V 50/60 Hz ETL IP20
Claypaky CD3004 Sharpy X Spot Moving Head Fixture
Overview
The Sharpy-X-Spot is a simplified Sharpy-X-Frame model, with all the same lighting, optical and construction features that have made the Sharpy-X-Frame so successful. First of all, it fits a powerful 550 Watt arc lamp, which makes this fixture extremely bright and produces deep, vivid, uniform colours, including an unparalleled deep red.
The effects section is outstanding. It includes a rotating, interchangeable HD gobo wheel, an 18-gobo fixed gobo wheel (including 6 beam diameter reducers), an exceptional animation wheel, and one four-sided and one eight-sided rotating prism, both on dedicated channels. Without a doubt, the Sharpy-X-Spot offers the lighting designer one of the most appealing effects sections on the market!
It is lightweight and compact, and features a linear frost filter and a colour system with CMY, CTO filter and a separate colour wheel. With a zoom range from 3° to 52° (spot mode) and 2° to 29° (beam mode), the Sharpy-X-Spot can create incomparable visual effects. The unit fits a 160mm (6.3 inch) front lens, and tried and tested Claypaky optical system for producing sharp images and collimated beams.
If needed, the “beam shaper” module – provided as an accessory – can be added, thus turning the Sharpy-X-Spot into a fully-fledged Sharpy-X-Frame! The module is automatically recognized by the product firmware.
The Sharpy-X-Spot is ideal for those who want a light with excellent performance and a cost/performance ratio without equal on the market.
Features
Light Source
550W arc lamp
Light Output
18,800 lm
Zoom range
3°-52° (spot mode) and 2°-29° (beam mode)
Effects
Linear CMY color mixing; Linear CTO; Fixed color wheel with 14 dichroic colors; 1 Rotating gobo wheel with 8 HD Indexable and replaceable gobos; 1 Static Gobo Wheel with 18 gobos; Linear heavy frost for wash effect; Animation wheel; 2 rotating prisms (4 and 8 facet); Motorized iris; Motorized Zoom and Focus; High resolution dimmer 16 bit; Shutter and Strobe effect
Specifications
Light Source Type
Philips 25R 550W lamp
CRI: 80+
Colour Temperature: 8000K
Lamp life expectancy: 1500 hrs
Lamp life expectancy: 1500 hrs
*It may vary depending on various factors, as type of use and environment
Photometric Data
Zoom range: 3° to 52° (Spot mode) – 2° to 29° (Beam mode)
18800 Lumen Output (Integrating Sphere)
Front lens diameter: 160mm
High efficiency optical system
Noise Level
Auto fan mode: 49.3 dBA
Control and Connections
Personalities: Single mode with 43 control channels
Control Protocol: DMX, Art-Net, RDM, sACN
DMX and RDM connectors: Locking 5 pin XLR IN/THRU
Ethernet port: RJ45 IN
Power connector: PowerCon True1
Built In Web Server
Dynamic Effects
Colours:
Linear CMY colour mixing (same as Sharpy X Frame)
Linear CTO
Fixed color wheel with 14 dichroic colors
Gobos:
1 Rotating gobo wheel with 8 HD Indexable and replaceable gobos Rotating gobo dimensions: Ext diam. 19 mm Image diam. 14.5 mm Thickness 1.1mm
1 Static Gobo Wheel with 18 gobos
Frost:
Linear heavy frost 5° for wash effect (same as Sharpy X Frame)
Rotating Effects
Aluminum animation wheel with continuous rotation in both direction at variable speed
2 prisms (4 and 8 facet) with rotation in both direction at variable speed
Iris:
Motorized with variable pulse and random effects
Movement:
Tilt: 270° - 16bit
Pan: 540° - 16bit
Accuracy: Resolution ± 0.27° (Range 0.54°)
Automatic repositioning
Fast/Standard speed selectable by Function channel
Mechanical Pan/Tilt lock for safe transportation and maintenance
Beam:
Motorized Zoom and Focus
Dimmer/Shutter:
High resolution dimmer 16 bit
Shutter and Strobe effect
Hardware and Software
Long life self-charging battery
Display Graphic LCD backlit b/w Display
Firmware upload from another fixture
Firmware Upgrade via Web Server
Diagnostic
DMX monitoring
Remote access through RDM
CloudIO compatibility
Housing
Aluminum and steel structure with plastic covers
Two side handles for transportation
IP20 protection rate
Working Position
Working in any position
Hanging system: with fast-lock omega clamps (1/4 turn) on the base
Optional safety chain
Electrical
Operating Voltage: 100-240V, 50/60 Hz
Power Supply: Electronic auto range with active PFC
Max Power consumption: 750VA
Thermal Specification
Max ambient temperature 45°C (113°F)
Min ambient temperature -20°C (-4°F)
Max temperature of the external surface 90°C (194°F)
Total heat dissipation: 2562 BTU/hr ±10% / 2700 kJ/hr ±10%
Safety Specs
Minimum distance of illuminated objects 8 meters (26’ 3”)
Minimum distance from flammable materials 0.2 meters (8”)
Fuse T10A – 250V
Thermally protected power supply (overheating and cooling failure)
Forced ventilation with axial fans
Compliance
CE: conforms to the European Directives
UKCA: conforms to UK Regulations
EAC: conforms to EurAseC Regulations
cMETus Listed
Packaging
Carton box + Polystyrene
Carton box + Foam shell
Flight case + Foam shell (2 positions)
Weight - Size
27 Kg (59.5 lbs)
306x350mm (base dimension) – 668 with vertical head (h)
Distance between two fixtures 505mm
Accessories
Omega clamps: 2x183102/805 (included)
Power cord: CAB02B/802 (included)
Foam shell: F21326/001 (optional)
Flight case 2 positions: CF1006 (optional)
Safety Chain: 105041/003 (optional)
