Description
Sharpy X-Frame:
550w Lamp, 8000k, 1500hrs
100-240V 50/60 Hz ETL IP20
Claypaky CD3003 Sharpy X Frame Moving Head Fixture
Overview
Adding to the family of the award-winning SHARPY fixtures, Claypaky introduces the SHARPY X FRAME multifunction luminaire. The SHARPY X FRAME takes the best features of the SHARPY line and integrates a four-focal plane shutter system in a lightweight, compact fixture. The unit’s source is the powerful 550- Watt arc lamp that makes this fixture extremely bright and produces deep and vivid uniform colors (including an unmatched deep red).
The unit boasts the flexibility to be the light you need when you need it. As a completely hybrid, multifunction fixture, the SHARPY X FRAME not limited as to beam effects, it can also be a spot, profile, or wash unit. This fixture replaces much larger luminaires using the longer life 550- Watt arc lamp.
Although a small fixture by most standards, nothing is sacrificed in the SHARPY X FRAME fixture’s feature set. In addition to the four-focal plane shutter system, the unit offers a rotating gobo wheel with eight rotating gobos, a static gobo wheel, four and eight-facet rotating prisms, linear frost, a color system featuring CMY, CTO and a separated color wheel, and six beam reducers starting at 0.5°.
With a zoom range from 3° to 52° (spot mode) and 2° to 29° (beam mode), the SHARPY X FRAME can do unparalleled visual effects. The unit is fitted with a 160mm front lens and proven Claypaky optics for producing sharp images and collimated beams.
The SHARPY X FRAME is the most versatile, compact hybrid fixture on the market that addresses the needs for a bright spot, aerial effects unit, framing fixture and everything in between in an affordable, compact package.
Features
Light Source
550W arc lamp
Light Output
18,800 lm
Zoom range
3°-52° (spot mode) and 2°-29° (beam mode)
Effects
Linear CMY color mixing; Linear CTO; Fixed color wheel with 14 dichroic colors; 1 Rotating gobo wheel with 8 HD Indexable and replaceable gobos; 1 Static Gobo Wheel with 18 gobos; 4-blade Framing system;Linear heavy frost for wash effect; Animation wheel; 2 rotating prisms (4 and 8 facet); Motorized iris; Motorized Zoom and Focus; High resolution dimmer 16 bit; Shutter and Strobe effect
Specifications
Light Source Type
Philips 25R 550W lamp
CRI: 80+
Colour Temperature: 8000K
Lamp life expectancy: 1500 hrs
*It may vary depending on various factors, as type of use and environment
Photometric Data
Zoom range: 3° to 52° (Spot mode) – 2° to 29° (Beam mode)
18800 Lumen Output (Integrating Sphere)
Front lens diameter: 160mm
High efficiency optical system
Noise Level
Auto fan mode: 49.3 dBA
Control and Connections
Personalities: Single mode with 43 control channels
Control Protocol: DMX, Art-Net, RDM, sACN
DMX and RDM connectors: Locking 5 pin XLR IN/THRU
Ethernet port: RJ45 IN
Power connector: PowerCon True1
Built In Web Server
Dynamic Effects
Colours:
Linear CMY colour mixing (brilliant and lighter Magenta in the Sharpy X Frame FD model)
Linear CTO
Fixed color wheel with 14 dichroic colorss
Gobos:
1 Rotating gobo wheel with 8 HD Indexable and replaceable gobos
Rotating gobo dimensions:
Ext diam. 19 mm
Image diam. 13.5 mm
Thickness 1.1mm
1 Static Gobo Wheel with 18 gobos
Framing system:
4 blades with +/- 60° rotation of the full system
“Total Curtain" effect allowing the full blackout with each single blade
Built In macros
Frost:
Linear heavy frost 5° for wash effect Sharpy X Frame
Linear light frost 2° for wash effect Sharpy X Frame FD
Rotating Effects
Aluminum animation wheel with continuous rotation in both direction at variable speed
2 prisms (4 and 8 facet) with rotation in both direction at variable speed
Iris:
Motorized with variable pulse and random effects
Movement:
Tilt: 270° - 16bit
Pan: 540° - 16bit
Accuracy: Resolution ± 0.27° (Range 0.54°)
Automatic repositioning
Fast/Standard speed selectable by Function channel
Mechanical Pan/Tilt lock for safe transportation and maintenance
Beam:
Motorized Zoom and Focus
Dimmer/Shutter:
High resolution dimmer 16 bit
Shutter and Strobe effect
Hardware and Software
Long life self-charging battery
Display Graphic LCD backlit b/w Display
Firmware upload from another fixture
Firmware Upgrade via Web Server
Diagnostic
DMX monitoring
Remote access through
Housing
Aluminum and steel structure with plastic covers
Two side handles for transportation
IP20 protection rate
Working Position
Working in any position
Hanging system: with fast-lock omega clamps (1/4 turn) on the base
Optional safety chain
Electrical
Operating Voltage: 100-240V, 50/60 Hz
Power Supply: Electronic auto range with active PFC
Max Power consumption: 750VA
Thermal Specification
Max ambient temperature 45°C (113°F)
Min ambient temperature -20°C (-4°F)
Max temperature of the external surface 90°C (194°F)
Total heat dissipation: 2562 BTU/hr ±10% / 2700 kJ/hr ±10%
Safety Specs
Minimum distance of illuminated objects 8 meters (26’ 3”)
Minimum distance from flammable materials 0.2 meters (8”)
Fuse T10A – 250V
Thermally protected power supply (overheating and cooling failure)
Forced ventilation with axial fans
Compliance
CE: conforms to the European Directives
UKCA: conforms to UK Regulations
EAC: conforms to EurAseC Regulations
cMETus Listed
Packaging
Carton box + Polystyrene
Carton box + Foam shell
Flight case + Foam shell (2 positions)
Weight - Size
28 Kg (61.7 lbs)
306x350mm (base dimension) – 668 with vertical head (h)
Distance between two fixtures 505mm
Accessories
Omega clamps: 2x183102/805 (included)
Power cord: CAB02B/802 (included)
Foam shell: F21326/001 (optional)
Flight case 2 positions: CF1006 (optional)
Safety Chain: 105041/003 (optional)
Sharpy X Frame to Sharpy X Frame FD conversion kit : CA3005000102 (optional)
Sharpy X Frame FD to Sharpy X Frame conversion kit : CA3006000102 (optional)
