Description
Arolla Aqua (Foam Shell):
900w 7000k White LED
100-240V 50 60HZ ETL IP66
Features
Light Source
custom 900W white LED engine (7000 K)
Light Output
40,000 lm
Zoom range
5.5°-50° (9:1) linear zoom
Effects
16-bit CMY color mixing; Linear CTO; Six-color wheel (including high CRI filter); 7 HD interchangeable rotating gobos; 8 HD interchangeable fixed gobos; Go-Bright Technology: no light loss or colour shift when gobos are inserted into the beam; Animation wheel; Four-sided rotating prism; 16-blade motorized iris; Framing system: four focal planes, +/- 60° rotation and macro channel control; Soft edge frost and flood frost filters; 24-bit digital dimmer with 4 user-selectable dimming curves; Digital stop-strobe effect
Specifications
Light Source Type
900W White LED Engine
CRI: 70+ with selectable filter for CRI 88+
Colour Temperature: 7000K
Lamp life expectancy: 40000 hrs
*It may vary depending on various factors, as type of use and environment
Photometric Data
Zoom range: 5.5°- 50°
18800 Lumen Output (Integrating Sphere)
Front lens diameter: 140mm
High efficiency optical system
Noise Level
Theatre fan mode: 40.0 dBA
SLN fan mode: 42.3 dBA
Constant fan mode: 50.2 dBA
Auto fan mode: 50.3 dBA
Control and Connections
Personalities: Single mode with 38 control channels
Integrated Wireless DMX system as standard (Wireless Solution / Lumen Radio)
Control Protocol: DMX, Art-Net, RDM, sACN
DMX and RDM connectors: Locking 5 pin XLR IN/THRU
Ethernet port: RJ45 IN
Power connector: PowerCon True1 INOUT
Built In Web Server
Dynamic Effects
Colors:
Linear 16bit CMY color mixing
Linear 16BIT CTO
Fixed color wheel with 6 dichroic colors
Gobos:
1 Static gobo wheel with 8 replaceable gobos
1 Rotating gobo wheel with 6 HD Indexable and replaceable gobos
Ext diam.26.95mm
Image diam. 20.5mm
Thickness 1.1mm
Framing system:
4 blades with +/- 60° rotation of the full system
“Total Curtain" effect allowing the full blackout with each single blade
Built In macros
Frost:
Linear heavy frost 5° for wash effect
Light frost 1° for soft diffusion
Rotating Effects:
Aluminum animation wheel with continuous rotation in both direction at variable speed
4 Facets prism with rotation in both direction at variable speed
Iris:
Motorized with variable pulse and random effects
Movement:
Tilt: 270° - 16bit
Pan: 540° - 16bit
Automatic repositioning
P/T Smooth speed selectable by Function channel
Mechanical Pan/Tilt lock for safe transportation and maintenance
Beam:
Motorized Zoom and Focus
Dimmer/Shutter:
High resolution electronic Dimmer - 24 bit
5 selectable by Function channel
Shutter and Strobe effect
Hardware and Software
Long life self-charging battery
Display Graphic LCD backlit b/w Display
Firmware upload from another fixture
Firmware Upgrade via Web Server
Diagnostic
DMX monitoring
Remote access through RDM
CloudIO compatibility
Housing
Aluminum and steel structure with plastic covers
Two side handles for transportation
IP66 protection rate
Working Position
Working in any position
Hanging system: with fast-lock omega clamps (1/4 turn) on the base
Optional safety chain
Electrical
Operating Voltage: 100-240V, 50/60 Hz
Power Supply: Electronic auto range with active PFC
Max Power consumption: 1100VA
Thermal Specification
Max ambient temperature 45°C (113°F)
Min ambient temperature -20°C (-4°F)
Max temperature of the external surface 90°C (194°F)
Total heat dissipation: 4782 BTU/hr ±10% / 5040 kJ/hr ±10%
Safety Specs
Minimum distance of illuminated objects 2.5 meters (8’ 2”)
Minimum distance from flammable materials 0.2 meters (8”)
Fuse T6.3A – 250V
Thermally protected power supply (overheating and cooling failure)
Forced ventilation with axial fans
Compliance
CE: conforms to the European Directives
UKCA: conforms to UK Regulations
EAC: conforms to EurAseC Regulations
cMETus Listed
Packaging
Carton box + Polystyrene
Carton box + Foam shell
Flight case + Foam shell (2 positions)
Weight - Size
38.7 Kg (85.3 lbs)
325x450mm (base dimension) – 750mm with vertical head (h)
Distance between two fixtures 700mm
Accessories
Omega clamps: 2x183102/805 (included)
Power cord: CAB0NL/802 (included)
Foam shell: F21340-001 (optional)
Flight case 2 positions: CF1024 (optional)
Safety Chain: 105041/001 (optional)
