AREA 48 Studio Kit (black), Curved yoke, Detachable Barndoors - Incl. 48 volt PSU mounted on unit, locking IEC , TVMP and chroma blue media

BBS-2038S
Regular price
$2,895.00
Sale price
$2,605.50

The 48V Solution
The Area 48 Remote Phosphor LED fixture offers a multitude of benefits including
48 Volt power to produce the most accurate dimming from 100 percent all the way
to zero—even in the last 5%. BB&S’s integrated LED technology moves the phosphor
away from the LED itself, thereby greatly improving color rendering, consistency, and light
output. The system’s color rendering accuracy is over 98 TLCI, with HD-friendly soft light
output comparable to a 1200W traditional soft light. Moreover, the phosphor panels are
interchangeable, allowing you to quickly change the fixture from Daylight to Tungsten,
to Chroma-Green, all in a matter of seconds.
AREA 48 Studio Features
• Chroma Green 525n, 98 TLCI 2700oK,
98 TLCI 3200oK, 98 TLCI 4300oK, 98 TLCI 5600oK,
98 TLCI 6500oK, Chroma Blue and
10,000K Phosphor Panels
• Extremely high light output
• Wide 160o light dispersion (95o w/optional softbox)
• Flicker-free dimming from 100%-0
• Silent operation (no fan)
• Internal DMX 512 for remote control
• Special effects strobing mode
• Compact and versatile fixture
AREA 48 Studio Includes
• Easily detachable barndoors
• Angled yoke with 3 1/2” female baby pin TVMP
• Power supply and locking AC power cord

AREA 48 STUDIO
SPECIFICATIONS
POWER
• Power Supply: 48V
• AC Power: 100-240V 50/60Hz
• Max Power Consumption: 145W
LED
• Premium LED Array - 50,000 hour life
CONTROL
• Precision dimming 100 percent to
zero even in the final 5 percent
• Manual dimming or DMX 512
• DMX in/out for daisy-chaining
• 8/16 bit dimming 100%-0
• Up to 4 control channels,
selectable via digital display
DIMENSIONS
W: 36cm / 14"
H: 28cm / 11"
D: 13cm / 5"
Weight: 3.6kg / 7.94 lbs
THERMAL
Ambient Operating Temperature:
0-40°C / 0-104°F

AREA 48 STUDIO
Brackets available to assemble 1x2 or 2x2 Area 48 lights, optional soft boxes and grids

48V Studio light Options
• Chroma Green 525n, 98 TLCI 2700oK , 98 TLCI 3200oK, 98 TLCI 4300oK,
98 TLCI 5600oK, 98 TLCI 6500oK, Chroma Blue and 10,000K Phosphor Panels
• Phosphor panel carrying case
• DoPchoice Snapgrid® and Snapbox® softboxes and grids
• 1 light and 2 light canvas cases
Product Benefits
• Wide spectrum quality soft light with visually accurate color temperature
• Smooth dimming from 100% to 0 with no color shift even in the last 5%
• Flicker-free performance at any frame rate or shutter angle
• Microprocessor controlled current management for long LED life
• Efficient power management for low power
consumption and high reliability
• Optomized for outstanding skintones
• Simple up/down menu operation button
• Superior quality daylight color
• Extremely lightweight (w/PSU)
3.9-kg/8.6-lbs
