in-lite AIM FLOOR - 99440000

AIM FLOOR by in-lite. 12V low-voltage landscape lighting and accessories for professional outdoor installations.

• AIM FLOOR is specially designed for use on terraces or under canopies. It combines cozy mood lighting with practical functionality. The lamp offers flexible positioning and adjustable light. Its sleek and minimalist design does not dominate the terrace. Despite its slim shape, it is tall, stable, and robust.

  Thanks to a modular connection, AIM can easily be expanded to three light sources. This unique connection also allows the light sources to rotate 360° infinitely. This means that the light from the AIM can be directed in any desired direction. Please note: AIM comes with one light source as standard.

  • Built-in KILLFLASH
  • Patented waterproof connection
  • Modular design allowing up to three light sources
  Product Details

  AIM FLOOR is part of the AIM concept. This consists of outdoor spotlights AIM, AIM LOW, AIM EXTRA LOW, and ceiling spotlight AIM CEILING. All these fixtures come with one light source and can be expanded with two additional AIM LIGHTHEADS.

  AIM FLOOR is a 12V & 21V fixture, but is also available in 120V. It can be connected directly to your power outlet using the ADAPTER.




  Specs

  Art. nr.

  99440000

  Application

  Canopy, Deck

  CRI

  90

  Diameter (inch)

  1.1

  Diameter (mm)

  28

  Energy label

  G

  Height (inch)

  59.1

  Height (mm)

  1500

  IP class

  55

  Length (inch)

  11

  Light direction

  Adjustable

  Types of Light

  Direct

  Efficiency (Lumen/Watt)

  70

  Net luminous flux (Lumen)

  84

  Power [W]

  1.2

  Processing

  Concrete, Natural stone, Wood

  Article group

  Path lights

  Voltage

  12 volt, 21V

  VA value

  2.1

  Width (mm)

  280

  Color temperature

  3000

  Material finishing/coating

  FCBV

  Kilowatt hour

  1

  Luminous intensity [Cd]

  157.7

  Power factor

  0.56




  Installation instructions

  See the manual.
  This product consists of two packages:
  - AIM FLOOR (add parts)
  - GRIP 3
  Twist the two parts of the tube together. Then twist the light source onto the tube and then the whole thing onto the base (GRIP 3). Connect the fixture with the EASY-LOCK and you're done! To add extra light sources, see the manual.



  PLEASE NOTE!
  - Screw the light source on, do not push it!
  - Maximum of 3 light sources on one fixture.




  Download AIM FLOOR manual here.




  Need help selecting compatible transformers, cables, and fixtures? Contact The LA Firm for project support.
